TURRET LATHE, Warner & Swasey #3 Square Head
TURRET LATHE, Warner & Swasey #3 Square Head
MODEL: M4630, S/N: 2536686, NEW: 1974
SWING OVER BED ............................ 15-3/8"
SWING OVER GUIDE .......................... 13-1/4"
SWING OVER CROSS SLIDE .................... 7"
HOLE THRU SPINDLE ......................... 1-27/32"
BAR CAPABILITIES (ROUND) ................ 1-1/2"
SQUARE .................................. 1-1/16"
HEXAGONAL ............................... 1-5/16"
SPINDLE TAPER ............................. AMERICAN A1-6"
SPINDLE SPEEDS (16) ....................... 45 - 2,262 RPM
MAX DIST FROM END OF SPINDLE TO FACE
OF HEX TURRET ........................... 26-7/8"
MAX. LONGITUDINAL TRAVEL ................ 17-3/8"
CROSS TRAVEL ............................ 8"
LONGITUDINAL ...... .003, .005, .007, .012, .019 & .029IN
CROSS ............. .002, .003, .005, .008, .013 & .020IN
MAX TURRET AT ONE SETTING ............... 10"
SIZE ACROSS FLATS ....................... 8-1/2"
DIAMETER OF TOOL HOLES .................. 1-1/2"
TURRET FEEDS LONG. .. .003, .005, .008, .013, .02 & .032IN
APPROX WEIGHT ............................. 5,200 LBS
- HYDRAULIC BAR FEED & COLLET CLOSER
- TAPER ATTACHMENT FOR FRONT CARRIAGE
- FRONT 4-WAY TURRET TOOL POST
- MISCELLANOUS TURRET TOOLING & COLLETS
- 5 / 10 HORSEPOWER TWO SPEED MAIN MOTOR
MACHINE IS WIRED FOR 3 PHASE 60 CYCLE 440 VOLT OPERATION
INSPECT UNDER POWER IN OUR NEW JERSEY WAREHOUSE!
Machine Location: HARRISON, NJ
