ARM7 tdmi nxp philips LPC2103 development board 32 bits

What is for sale: ARM7 tdmi nxp philips LPC2103 development board 32 bits

---

ARM7 TDMI NXP Philips LPC2103 Development board 32 Bits
Our new ARM2103 Controller is one of the most powerful controllers currently available. Utilizing the new high-performance LPC2103 microcontroller from Philips. This controller features both high-speed, large memory capacity and a host of useful peripheral features for the most demanding embedded application. All mounted on a very compact board with easy to connect headers, on-board regulator and direct program download.
The new LPC2103 Microcontroller from Philips includes a large 32kB Flash Program Memory, ideal for the largest of applications. Together with 8kB of Data Ram space, making the microcontroller ideal for use in data gathering systems. The microcontroller is designed for high-speed applications with a maximum speed of up to 58MHz. The LPC2103 also includes a host of useful auxiliary features, including a high conversion speed 10-bit 8-channel A/D convertor, 2 channel UART, 2 SPI and I2C buses, plus a real-time clock and a load of high accuracy timers. A total of 32 I/O points are available, these are connected to standard headers on the controller, for easy connection and removal.
All the necessary support components are included, together with a Power LED, voltage regulator, Two RS232 UART's, LCD Connector with contrast adjustment, plus a reset and load switch for program execution and download. Programs can be downloaded directly via a standard RS232 serial connection, utilizing one of the RS232 ports on-board. Easy to use Windows® download software is included and this is suitable for Windows® XP/98/ME.
Our new ARM2103 Controller is the perfect solution for ARM enthusiasts, looking for a high-powered board for their embedded applications. The board is compact and can easily fit into small controller enclosures, with the necessary support components already fitted, together with easy-to-connect interface connectors to make installation a breeze. The ARM2103 Controller is ideal for high-performance control solutions.
• Includes Philips LPC2103 Microcontroller with 32kb Internal Flash Program Memory
• Operating Speed up to 58.9824MHz
• Direct In-Circuit Programming for Easy Program Updates
• Up to 32 I/O points with easy to connect standard headers
• 2 RS232 Connections with MAX232
• Two 32-bit Timers and Two 16-bit Timers
• LCD Connection with Contrast Adjustment
• Ideal as an Interchangeable Controller for Real-Time Systems
ARM2103 Controller - Technical Data
• Program Flash Memory (Internal): 32kBytes
• RAM Memory - Scratchpad (Internal): 8 kBytes
• EEPROM Memory (Internal): None
• I/O Points Connection: IDCC Connector
• A/D: Yes - 8 Channels 10-bit accuracy
• Timers: Yes - Two 32-bit Timers and Two 16-bit Timers
• Capture and Compare Channels: Yes - Total 10 channels
• RTC: Yes - with external 32.768kHz Crystal
• RS232 Communication: Yes - 2 UART's
• SPI Communication: Yes - SPI and SPP
• I2C Communication: Yes - 2 Channels Fast I2C (400kbit/s)
• In-Circuit Programming: Yes - via RS232 Connection
• LCD Connection: Yes - with Contrast Adjustment
• Power-Supply: 5 Vdc - On-Board 3.3V regulator
• LxWxH: 82mm x 62mm x 25mm (Including mounting supports)
• Included Parts: ARM2103 Controller, Serial Connector, Download Software, Manual on CD, Examples and Sample Code, Data Sheets on CD.
