Conceptronic hvc 70 reflow oven

What is for sale: Conceptronic hvc 70 reflow oven

---

CONCEPTRONIC HVC 70 REFLOW OVEN
CONCEPTRONIC HVC 70 REFLOW OVEN
The HVC 70 is the only forced impingement convection oven that maintains maximum operating flows regardless of operating atmosphere (i.e., standard air-only or optional air/nitrogen). Its extremely high linear convective impingement ratio and high impingement velocities enable it to outperform competitive systems with far longer heating chambers. As a result, product heating is more uniform, profiling is more intuitive and operating power consumption is low.
Both the heating and cooling chambers incorporate our exclusive "filterless" flux and flow management technology (patent pending). This technology is designed to provide more consistent, long-term performance and maximum uptime. In the heating chamber, this technology comes with a 5-year "no flow change, no cleaning" guaranty!
In the cooling section, our standard Polaris air only coolers and optional Genesis air/nitrogen coolers isolate and collect flux effluents through inertial separation and cold surface precipitation. This approach extends maintenance intervals up to every 6 months (in comparison to the weekly maintenance required with filter-based systems)!
• WindowsTM, graphic interface software.
• 5 vertical heating zones (5 heaters top and 5 bottom).
• 70-inch/178 cm heating chamber with 49-inches/124 cm of total linear impingement.
• Low mass, fast responding convection zones.
• 27-inch/68 cm "dual-zone" enclosed cooling section.
• "Filterless" flux and flow management in heat chamber (with 5-year, "no maintenance" guaranty).
• "Filterless" flux and flow management in cooling chamber.
• 3-year blower motor warranty.
• Computerized control of heating, cooling and conveyor system functions.
• Virtually unlimited capability for thermal profile generation.
• Intuitive setup and operation.
• Peak temperature repeatability to within +/- 1%.
• Real-time, multi-point recording of product time/temperature thermal curves.
• Unlimited capacity for storage of profile "recipes" and time/temperature thermal curves.
• Durable, low maintenance design for maximum "uptime".
For more detailed technical information on this model, please contact the factory and request "Standard Machine Specification" and/or "Option Description" documents.
Information provided by conceptronic's web site.
Unit does not include the cpu or software.
Physical Condition ~ Cosmetic Appearance
Good ~ "Normal signs of wear and tear"
Original packaging is missing.
No Warranty Given, Expressed or Implied
This item is eligible for pickup unless otherwise stated.
