South bend 10" 13" 14½" 16" &16/24" lathes manual/parts

What is for sale: South bend 10" 13" 14½" 16" &16/24" lathes manual/parts

---

This is a reproduction, not a photocopy, of an original South Bend 10"-24" Lathes Parts Manual. What is great about this manual is that it contains information and parts list for the South Bend 10",13",14½", 16" and 16/24". Manual also contains parts numbers for metric parts. This manual contains information on lubrication, adjustments, maintenance, and controls as well as a complete parts list with exploded view diagrams for all lathes. Dont' forget to check out my other items!
Some of the lathes made for the time frame covered by this manual were made without gear boxes for threading, but some did have a gear box. Below is a picture of the gear box that was used in this time frame.
Machine Care....................................................1
Headstock .................................................2,3
Headstock Gears........................................4,5
Gear Box ...................................................6,7
Cover and Lead Screw..................................7
Tailstock.....................................................8,9
Saddle.....................................................10,11
Apron.....................................................12,13
Big Gear Box Cover...............................14,15
Underneath Drives..................................15-19
Bench..........................................................19
Motor Cabinet........................................20,21
Compound Rest......................................22,23
Bed and Leg...........................................24,25
I have collected this information for many years and have found the information they contain to be priceless in using and setting up the machines properly. I believe this manual will be a valuable resource of knowledge that will provide a lot of helpful information that is often hard to find. My manuals are not photocopies. I maintain a high standard of quality in my reproductions. Most of the manuals I reproduce look better than their originals. I have professionally digitally edited every page, and removed stains, wrinkles and handwriting. All of the manuals are printed on thick white paper to withstand shop wear and tear; they are then comb bound with heavy cover pages so they lie flat on the workbench.
Be sure to add me to your favorites list!
I am adding new manuals all the time.
PLEASE READ the return policy and COMPLETE description of the manual.
Because of the nature of this product, I do not accept any returns or exchanges
under any circumstances. If you have any questions email me or send me a picture first. I
