Honeywell Q5001D1000 valve linkage for modiii and modiv

What is for sale: Honeywell Q5001D1000 valve linkage for modiii and modiv

---

Valve Linkage for Mod III and Mod IV motors
The Q5001 Valve Linkage connects a Modutrol® Motor to a 2- or 3-way valve. It is used primarily on V5011 or V5013 steam and water valves.
• Q5001 Valve Linkage is applicable to 2-Way or 3-Way valves in modulating or two-position service.
• Linkage requires no adjustment when used with Honeywell valves and Modutrol IV™ Motors.
• Q5001 Valve Linkage replaces Q601 and Q618 Valve Linkages.
• Linkage mounts directly to the valve bonnet; motor mounts to linkage bracket.
• Easy-to-read position indicator.
• Valve stem lift height cam selectable.
• Overtravel permits tight close-off without excessive motor strain.
• Available brackets make linkages adaptable to many valve bodies.
• Models available with 80 lb, 160 lb, and 320 lb stem force.
• Reversible cams on the Q5001 allow field selection of normally open or normally closed valve operation.
Valve Linkage for Mod III and Mod IV motors with 80 or 160 lb stem force
Linkage mounts directly to the valve bonnet; motor mounts on linkage bracket.
1 3/8 in. valve bracket and Anti spin clip
