Tek 7D14 svc / op manual 2 res+A3+A4+textsearch+ extras

What is for sale: Tek 7D14 svc / op manual 2 res+A3+A4+textsearch+ extras

---

Tektronix 7D14 Service and Operating Manual in both Very High and in Standard Resolution PDFs on CD
Why settle for just one resolution? You get them both!
For page samples from the high res PDF of this specific manual, click HERE.
(No need to "email for samples," so no need to worry about getting sold to a SPAM list!)
(Please read FAQ or "About Me" Page)
Thank you for considering purchase of these very high-resolution and standard resolution scanned copies of the SERVICE AND OPERATING MANUAL for the Tektronix Model 7D14 Plug-In. These volumes are each composed of the entire contents of the original manual. We supply PDFs in both a very high res and a faster, less resource-demanding "standard" resolution. The standard res A4 Manual PDF is also TEXT-SEARCHABLE.
This PDF Set includes maintenance and calibration procedures, complete parts lists, board component locators and schematic diagrams, plus full operating information.
SCAN PARAMETERS (Very High Res PDF):
Text with photos: 600dpi grayscale (contrast adjusted)
Text with Drawings: 600dpi black and white
Schematics: 600dpi black and white
Schematics and PCB Photos w/Color (if any): 400-600dpi 24-bit color
Foldouts supplied as -BOTH- 11x17" -AND- 8.5x11" scans
Chapter-Page (as in paper manual) -AND- Sequential Page Numbers
Scan parameters of the standard res PDF: The standard res PDF is done in resolutions that vary depending on individual page content, but are never higher than needed to produce a useable quality, quickly navigable file that will do the job without consuming more time and resources than are needed.
"AND IF THAT'S NOT ENOUGH FOR YOU":
As "bonus" material, includes the Tektronix Semiconductor Parts Catalog, plus an interesting and informative Articles PDF as well as a useful text-searchable scan of the 1990 Tektronix Catalog, featuring almost 3,000 Tektronix Products, all at no additional charge.
