Jet model 1325PDB 13" x 36" cc table top lathe


What is for sale: Jet model 1325PDB 13" x 36" cc table top lathe

EscrowUnlt © AP6.0JET MODEL 1325PDB 13" X 36" CC TABLE TOP LATHE
Swing Over Cross Slide: 7 25/32"
Hole Through Spindle: 1 17/32"
Hi: 140, 200, 300, 580, 850 And 1,240 RPM
Low: 60, 90, 130, 240, 350 And 500 RPM
6" Diameter 3 Jaw Scroll Chuck With Wrench
And Removable/Reversable Step Jaws
Tailstock With No. 2 Morse Taper Nose
Four Side Square Tool Post With Miscellaneous Cutters, (See Photo)
Graduated Hand Dials In Inch And Metric
Cross Slide: 11=0.001"/11=.02mm
Forward/Reverse Drum Switch On Main Drive
1 1/2 HP, 115/230 Volt, Single Phase Motor,
(Currently Wired For 115 Volt)
This Is A Bench Top Belt Driven Single Phase Jet Lathe!
Approximate Dimensions: 35" FB x 62" LR x 49" H
